Skid Steer Loaders / Export model
HLY25 Wheeled Skid Steer Loader
HLY25 is a Hongli wheeled skid steer loader with technical data verified against the supplied product catalog. Final order configuration is confirmed for the destination market.
- Operating Weight
- 300 kg
- Bucket Capacity
- 0.2 m³
- Rated Power
- 22.2 kW
Evidence before quotation
Confirm the machine before you order
Use the current model photos and verified specifications on this page, then ask our export team for the configuration and shipment records required for your order.
- 3 model photosMatched to this product record
- Specification checkConfiguration confirmed before quotation
- Pre-shipment evidencePacking and loading photos available on request
Product Overview
Built for work. Ready for export.
HLY25 is a Hongli wheeled skid steer loader with technical data verified against the supplied product catalog. Final order configuration is confirmed for the destination market.
Key Specifications
- Model
- HLY25
- Rated Operating Capacity
- 300 kg
- Maximum Speed
- 9 km/h
- Rated Flow
- 37 L/min
- Tire/Track Model
- 23×8.5 – 15
- Rated Power
- 22.2 kW
- Fuel Tank Capacity
- 25 L
- Operating Weight with Bucket
- 1500 kg
- Bucket Capacity
- 0.2 m³
- Overall Operating Height
- 3126 mm
Verified model data
Technical Specifications
Standard Configuration
- Model
- HLY25
- Rated Operating Capacity
- 300 kg
- Maximum Speed
- 9 km/h
- Rated Flow
- 37 L/min
- Tire/Track Model
- 23×8.5 – 15
- Rated Power
- 22.2 kW
- Fuel Tank Capacity
- 25 L
- Operating Weight with Bucket
- 1500 kg
- Bucket Capacity
- 0.2 m³
- Overall Operating Height
- 3126 mm
- Height to Bucket Hinge Pin
- 2399 mm
- Height to Top of Cab
- 1813 mm
- Height to Bucket Bottom (Level)
- 2399 mm
- Length without Bucket
- 1918 mm
- Overall Length with Bucket
- 2560 mm
- Dump Angle at Maximum Height
- 36 °
- Dump Height
- 1882 mm
- Dump Reach
- 458 mm
- Bucket Rollback Angle at Ground Level
- 24 °
- Bucket Rollback Angle at Maximum Height
- 97 °
- Wheelbase
- 722 mm
- Operating Weight
- 300 kg
Attachments & Options
Bucket, forks, auger, breaker, sweeper and other quick-attach tools are available by application.
Export Packing
Packaging dimensions and shipping gross weight are not provided in the source catalog and must be confirmed after final packing.
Typical Applications
Farms and yards / Road maintenance / Landscaping / Loading and material handling
