Skid Steer Loaders / Export model

HLY65 Wheeled Skid Steer Loader

HLY65 is a Hongli wheeled skid steer loader with technical data verified against the supplied product catalog. Final order configuration is confirmed for the destination market.

Operating Weight
3350 kg
Bucket Capacity
0.5 m³

Confirm the machine before you order

Use the current model photos and verified specifications on this page, then ask our export team for the configuration and shipment records required for your order.

  • 3 model photosMatched to this product record
  • Specification checkConfiguration confirmed before quotation
  • Pre-shipment evidencePacking and loading photos available on request

Reference configuration: 950 kg rated operating capacity · 0.5 m³ bucket · 3,350 kg operating weight · 1,880 mm width with bucket.

The Hongli HLY65 is a wheeled skid steer loader with a catalog-rated operating capacity of 950 kg and a 0.5 m³ bucket. Its reference specifications include 75 L/min rated hydraulic flow, 2,400 mm dump height and 3,100 mm height to the boom pivot pin. The catalog lists a 3,350 kg operating weight and 1,880 mm width with bucket. Confirm the actual bucket, tires, engine and attachment package in the order specification.

Choosing a loader for a particular material? Send Hongli Machinery the material type and expected load mass, required attachment, receiving height, route dimensions, destination country and expected quantity. Request an HLY65 configuration check before deciding whether its reference capacity fits your work.

The Bucket Can Look Full Before You Know What It Weighs

The HLY65’s 0.5 m³ bucket figure describes volume. Its 950 kg rated operating capacity describes a separate load rating. Neither number means every full bucket is an acceptable load.

Consider a numerical example using assumed bulk densities, rather than a claim about a particular material. A 0.5 m³ volume at 1,200 kg/m³ contains 600 kg of material. The same volume at 2,000 kg/m³ contains 1,000 kg. Both can occupy the same bucket volume, but the second material mass alone exceeds the HLY65’s listed 950 kg reference rating.

The 600 kg example is not an operating approval either. The actual bucket, attachment mass and load position, rating conditions and machine configuration still have to be checked. Do not universally subtract a guessed bucket weight from the catalog rating: first establish what attachment and conditions that rating already includes.

The practical lesson is to select the bucket and machine together. Ask what the material weighs in its actual handled condition, how the bucket capacity is defined and what load is approved with that attachment. Moisture and fill condition can change the answer. A photograph of a full bucket cannot establish the load mass.

A larger-volume bucket can be useful for a suitably light material, but it is not a capacity upgrade to the loader. A heavier attachment or a load held farther forward also needs its own assessment. These checks matter more than choosing a bucket simply because it fits the mounting plate.

HLY65 catalog working-range drawing listing 2400 mm dump height and 3100 mm bucket hinge-pin height
HLY65 catalog reference: 2,400 mm dump height and a separately listed 3,100 mm pin height. Confirm the selected bucket and actual loading position.

Who Should Consider the HLY65?

The HLY65 is worth assessing for yard loading, material transfer and site cleanup where a 0.5 m³ bucket and the approved capacity of the selected build suit the material. Its reference 1,880 mm bucket width and 2,400 mm dump height provide useful starting points for checking the travel route and receiving vehicle.

It can also be considered when comparing the next step above the HLY45’s listed 700 kg capacity and 0.4 m³ bucket. That comparison should include the wider bucket, greater machine mass and actual loading geometry, rather than assuming that a larger model will automatically improve the whole job.

When the HLY65 Is the Wrong Choice

Choose a different package if the required material load exceeds the approved capacity, the receiving edge cannot be cleared with the selected bucket, or the travel route cannot accommodate the full machine-and-attachment envelope. A narrower replacement bucket does not prove the machine itself will fit a restricted opening.

If your work depends on a high-flow attachment, do not order the HLY65 on the basis of its 75 L/min rated-flow entry. Its technical table does not specify a high-flow system. Confirm an appropriate hydraulic package or compare another model before committing to the tool.

For soft ground, finished surfaces or frequent turning in a confined area, describe the surface and travel pattern. The catalog does not provide ground-pressure or surface-damage measurements that would justify a blanket suitability claim.

HLY65 Reference Specifications

The following values describe the supplied reference configuration. Confirm the current offered build and any attachment-specific limits before ordering.

Item Reference specification
Model HLY65 wheeled skid steer loader
Rated operating capacity 950 kg
Tipping load 1,900 kg
Bucket capacity 0.5 m³; capacity measurement basis not stated
Operating weight 3,350 kg
Maximum travel speed 12 km/h
Tire model 10-16.5
Rated hydraulic flow 75 L/min
High-flow system Not specified in the technical table
Fuel tank capacity 80 L
Hydraulic oil tank capacity 80 L
Height to boom pivot pin 3,100 mm
Overall height 2,160 mm
Length with bucket 3,490 mm
Length without bucket 2,750 mm
Width with bucket 1,880 mm
Gauge, catalog label “Track Width” 1,500 mm; confirm measurement points
Wheelbase 1,085 mm
Ground clearance 205 mm
Dump height 2,400 mm
Maximum reach 750 mm
Reference engine designation 498T; confirm manufacturer and exact offered model
Reference rated engine power and speed 55 kW at 2,450 rpm; gross/net basis not stated
Reference engine displacement 3.168 L

Engine entries refer to the supplied model parameter sheet. They do not establish the engine offered for every destination or prove an emissions certification. Request the exact engine identification and applicable documentation with the quotation.

HLY65 catalog dimension drawing showing 1880 mm width with bucket, 2160 mm height and 1085 mm wheelbase
The catalog lists 1,880 mm width with bucket, 2,160 mm overall height and a 1,085 mm wheelbase. Confirm the complete order configuration and transport envelope.

Read the Load and Height Figures Separately

The 1,900 kg Tipping Load Is Not a Working Allowance

The HLY65 table lists both 950 kg rated operating capacity and 1,900 kg tipping load. Do not use the larger number as permission to carry that load. The supplied technical data does not establish the complete test conditions or the approved capacity for every attachment.

For pallet handling, request the approved fork configuration and capacity at the intended load position. Include pallet dimensions and load distribution. The bucket’s reference rating is not a universal fork rating or a lifting chart for suspended loads.

A 3,100 mm Pivot Height Does Not Mean 3,100 mm Dump Clearance

The listed dump height is 2,400 mm. The 3,100 mm pin-height entry describes a different point. Before selecting a receiving vehicle, check its edge height, required reach and the position of the bucket as it discharges.

The maximum reach is listed as 750 mm. The source does not establish that every maximum occurs at the same bucket position. Ask for a matched loading-envelope check instead of combining the height and reach limits into a guaranteed loading position.

Transport Uses the Actual Shipping Configuration

The reference operating weight is 3,350 kg. The machine may ship with a different bucket, additional attachments or packing. Obtain the actual shipment mass and dimensions, and account for separately shipped equipment. Neither the operating-weight entry nor the length-with-bucket figure is a complete transport specification.

Which Options Are Worth Discussing?

Start with a bucket suited to the material and receiving point. Confirm its capacity definition, mass, width and discharge geometry. Choose cutting-edge or bucket construction details for the task, without treating an attachment change as an automatic increase in allowable payload.

For a powered tool, obtain the required flow range, pressure, return-backpressure limit, case-drain arrangement and controls. Then confirm the machine’s actual auxiliary supply and cooling suitability for that duty. The listed 75 L/min rated flow is not a guarantee of continuous flow at an attachment connection.

The 10-16.5 tire designation identifies the reference size, not every tire’s construction, load rating or suitability for the surface. Ask for the actual tire specification when sharp debris, surface sensitivity or travel conditions are important.

For the engine, prioritize an identifiable offered model, appropriate documentation and a service plan for the destination. Do not infer certification from the 498T designation or the 55 kW power entry.

HLY65 Compared with HLY45 and HLY75

The HLY45 wheeled skid steer loader has reference values of 700 kg rated operating capacity, a 0.4 m³ bucket, 1,740 mm bucket width and 3,100 kg operating weight. The HLY65 increases the listed capacity to 950 kg and bucket volume to 0.5 m³, while bucket width becomes 1,880 mm and operating weight becomes 3,350 kg. Check whether that trade fits the route and material.

The HLY75 wheeled skid steer loader also lists a 0.5 m³ bucket and 1,880 mm width with bucket. Those matching headline dimensions do not make it the same machine. Its reference rated operating capacity is 1,050 kg, operating weight is 3,500 kg and listed pin height is 3,500 mm, compared with the HLY65’s 950 kg, 3,350 kg and 3,100 mm.

The difference in dump height is smaller: 2,450 mm for HLY75 versus 2,400 mm for HLY65. A 400 mm increase in listed pin height therefore does not translate into 400 mm more listed dump clearance. Compare the actual discharge geometry rather than choosing from pin height alone.

HLY75 also lists 80 L/min rated flow and a 120 L/min high-flow entry. Confirm the offered package and attachment requirements; those figures do not establish compatibility by themselves. HLY65 can remain a candidate when its approved capacity and loading envelope meet the task. HLY75 is worth examining when the additional reference capacity or an identified hydraulic configuration addresses a real requirement.

HLY65 Buyer Questions

Can the HLY65 carry a full 0.5 m³ bucket of any material?

No. Bucket volume does not establish material mass. Check the actual material, fill condition and approved load with the selected bucket. A different bucket can change the assessment even when its nominal volume is unchanged.

Is the HLY65 a 950 kg or 1,900 kg loader?

The supplied table lists 950 kg rated operating capacity and 1,900 kg tipping load. They are different figures. The tipping-load value is not a working-load allowance.

Why compare HLY65 and HLY75 if both have a 0.5 m³ bucket?

Their listed load ratings, machine masses, pin heights and hydraulic entries differ. The same bucket volume and width do not establish the same loading capability or attachment package.

Does 3,100 mm pin height let it dump into a vehicle that high?

No. Listed dump height is 2,400 mm, and bucket position and required reach must also be checked. Request the geometry for the selected bucket and receiving point.

Does HLY65 have a high-flow hydraulic system?

The supplied technical table does not specify one. Confirm the actual auxiliary package before ordering a tool; the 75 L/min rated-flow value alone is insufficient.

What engine will my HLY65 have?

The reference parameter sheet lists 498T and 55 kW at 2,450 rpm. Ask for the manufacturer, exact offered engine, applicable emissions documentation and service arrangements in the quotation. The reference designation is not proof of a destination-compliant package.

Request an HLY65 Configuration and Quotation

Send Hongli Machinery the information needed to select a complete package:

  • Destination country, delivery port and expected quantity.
  • Material or load type, actual load mass and required attachment.
  • Receiving-edge height, loading opening and required reach.
  • Narrowest travel width, entrance height and turning space.
  • Ground conditions and planned machine transport.
  • Powered attachment specifications, including flow, pressure, return and drain requirements.

Ask for an HLY65 configuration proposal. Request the confirmed engine and tire specifications, attachment-specific capacity, loading geometry, shipment mass and documentation before finalizing the order. Pricing and availability depend on the confirmed package.
